Basic spectification
Drainage | 40A | Gas port | |
---|---|---|---|
Water supply(a) | 15A | Applicable water pressure | 2~5kg/㎠ |
Power consumption(kW) | 10.2kW | Circuit breaker capacity | 30A |
Wire thickness | 5.5㎟ | Trolley weight(kg) | |
Shelf intervals | 67mm | Power | 3-phase AC380V / 60Hz |
cooking capacity | 200 | Size(WxDxH)mm | 898x772x758 |
Weight(kg) | 110 | no. of layers | 6 layers |
Gas consumption
LPG(kW, kg/h) | LNG(kW, kcal/h) |
---|
Temperature range(humidity)
Steam | 30~130℃ (100%) | Convection | 30~300℃(0%) |
---|---|---|---|
Combi | 30~300℃ (1~99%) |
